Product Summary

The BUV298AV is an NPN transistor power module. The applications of the BUV298AV include motor control, SMPS & UPS, welding equipment.

Parametrics

BUV298AV absolute maximum ratings: (1)VCEV Collector-Emitter Voltage (VBE = -5 V): 1000 V; (2)VCEO(sus) Collector-Emitter Voltage (IB = 0): 450 V; (3)VEBO Emitter-Base Voltage (IC = 0): 7 V; (4)IC Collector Current: 50 A; (5)ICM Collector Peak Current (tp = 10 ms): 75 A; (6)IB Base Current: 10 A; (7)IBM Base Peak Current (tp = 10 ms): 16 A; (8)Ptot Total Dissipation at Tc = 25 ℃: 250 W; (9)Tstg Storage Temperature: -55 to 150 ℃; (10)Tj Max. Operating Junction Temperature: 150 ℃; (11)VISO Insulation Withstand Voltage (AC-RMS): 2500 V.

Features

BUV298AV features: (1)NPN transistor; (2)high current power bipolar module; (3)verylow rth junction case; (4)specified accidental overload areas; (5)isolatedcase (2500v rms); (6)easy to mount; (7)low internal parasitic inductance.

Diagrams

BUV298AV block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BUV298AV
BUV298AV
STMicroelectronics
Transistors Bipolar (BJT) NPN Power Module LTB 9-2009
Data Sheet
Negotiable
