Product Summary
The TMS320F2407APGEA is a DSP controller. The TMS320F2407APGEA is optimized for digital motor/motion control applications. The TMS320F2407APGEA DSP controller combines the enhanced TMS320 architectural design of the C2xLP core CPU for low-cost, high-performance processing capabilities and several advanced peripherals optimized for motor/motion control applications. These peripherals include the event manager module, which provides general-purpose timers and compare registers to generate up to 12 PWM outputs, and a dual10-bit analog-to-digital converter (ADC), which can perform two simultaneous conversions within 6.1 ms.
Parametrics
TMS320F2407APGEA absolute maximum ratings: (1)Supply voltage range, VDD: -0.3 V to 7 V; (2)Input voltage range: -0.3 V to 7 V; (3)Output voltage range: -0.3 V to 7 V; (4)Operating free-air temperature range, TA: L version: 0 to 70℃; A version: -40 to 85℃; S, Q versions: -40 to 125℃; (5)Storage temperature range, Tstg: -55 to 150℃.
Features
TMS320F2407APGEA features: (1)12 Compare/Pulse-Width Modulation (PWM) Channels; (2)Three 16-Bit General-Purpose Timers With Six Modes, Including Continuous Upand Up/Down Counting; (3)Three 16-Bit Full-Compare Units With Deadband; (4)Three 16-Bit Simple-Compare Units; (5)Four Capture Units (Two With Quadrature Encoder-Pulse Interface; (6)Capability); (7)Dual 10-Bit Analog-to-Digital Conversion Module; (8)28 Individually Programmable, Multiplexed I /O Pins; (9)Phase-Locked-Loop (PLL)-Based Clock Module; (10)Watchdog Timer Module (With Real-Time Interrupt); (11)Serial Communications Interface (SCI) Module; (12)Serial Peripheral Interface (SPI) Module; (13)Six External Interrupts (Power Drive Protect, Reset, NMI, and Three Maskable Interrupts); (14)Four Power-Down Modes for Low-Power Operation; (15)Scan-Based Emulation.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
TMS320F2407APGEA |
Other |
Data Sheet |
Negotiable |
|
||||||
