MAX707ESA+

supervisor circuit, cost−effective, 12μA, 200 mS, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	0.60 / Piece
51 ~ 500 :	0.45 / Piece
501 ~ 5000 :	0.30 / Piece

PartNumber:: MAX707ESA+

Brand:: Maxim Integrated Products - Maxim | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Chan's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-10

From Other Seller

Part Number:MAX707ESA+
US $0.30 - 0.60
Quantity:

piece

Product Summary

The MAX707ESA+ is a cost-effective system supervisor circuit designed to monitor VCC in digital systems and provide a reset signal to the host processor when necessary. No external components are required. The reset output is driven active within 20 μsec of VCC falling through the reset voltage threshold. Reset is maintained with 200 mS of delay time after VCC rise above the reset threshold. The MAX707ESA+ has a low quiescent current of 12μA at VCC = 3.3 V, an active-high RESET and active-low RESET with a push;pull output. The output is guaranteed valid down to VCC = 1.0 V. The MAX707ESA+ has a Manual Reset MR input and a +1.25 V threshold detector for power;fail input PFI. Applications include Computers, Embedded System, Battery Powered Equipment and Critical μP Power Supply Monitor.

Parametrics

MAX707ESA+ absolute maximum ratings: (1)Supply Voltage: 6.0 V; (2)Output Voltage: -0.3 to (VCC + 0.3) V; (3)Output Current (All Outputs): 20 mA; (4)Input Current (VCC and GND): 20 mA; (5)Operating Ambient Temperature: -40 to +85℃; (6)Storage Temperature Range: -40 to +125℃.

Features

MAX707ESA+ features: (1)Reset Threshold Available from 1.6 V to 4.9 V with 100 mV Increments (Factory Option); (2)200 mS (Typ) Reset Timeout Delay; (3)12 μA (VCC = 3.3 V) Quiescent Current; (4)Active_High and Active_Low Reset Output; (5)Guaranteed RESET_L and RESET Output Valid to VCC = 1.0 V; (6)Voltage Monitor for Power-Fail or Low-Battery Warning; (7)8 Pin SOIC or Micro8 Package; (8)Pb-Free Packages are Available.
