MSP430F155IPMR

ultralow power microcontroller, QFP-64, -0.3 V to 4.1 V, Five Power-Saving Modes, 16-Bit RISC Architecture

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.50~5.00

PartNumber:: MSP430F155IPMR

Brand:: Texas Instruments - TI | Pack: QFP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Chan's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-07

From Other Seller

Part Number:MSP430F155IPMR
US $3.50 - 5.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MSP430F155IPMR is an ultralow power microcontroller. It consists of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low power modes is optimized to achieve extended battery life in portable measurement applications. The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that attribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6μs. Typical applications of MSP430F155IPMR include sensor systems, industrial control applications, hand-held meters, etc.

Parametrics

MSP430F155IPMR absolute maximum ratings: (1)Voltage applied at VCC to VSS: -0.3 V to 4.1 V; (2)Voltage applied to any pin: -0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg: (unprogrammed device): -55℃ to 150℃; (programmed device): -40℃ to 85℃.

Features

MSP430F155IPMR features: (1)Five Power-Saving Modes; (2)Wake-Up From Standby Mode in less than 6 μs; (3)16-Bit RISC Architecture, 125-ns Instruction Cycle Time; (4)Three-Channel Internal DMA; (5)12-Bit A/D Converter With Internal Reference, Sample-and-Hold and Autoscan Feature; (6)Dual 12-Bit D/A Converters With Synchronization; (7)16-Bit Timer_A With Three Capture/Compare Registers; (8)16-Bit Timer_B With Three or Seven Capture/Compare-With-Shadow Registers; (9)On-Chip Comparator; (10)Serial Communication Interface (USART0), Functions as Asynchronous UART or Synchronous SPI or I2CTM Interface.
