Product Summary

The DESI30-06A is a fast recovery epitaxial diode. The applications of the DESI30-06A are: Antiparallel diode for high frequency switching devices; Anti saturation diode; Snubber diode; Free wheeling diode in converters and motor control circuits; Rectifiers in switch mode power supplies (SMPS); Inductive heating and melting; Uninterruptible power supplies (UPS); Ultrasonic cleaners and welders.

Parametrics

DESI30-06A absolute maximum ratings: (1)TVJ: -40 to +150 ℃; (2)TVJM: 150 ℃; (3)Tstg: -40 to +150 ℃; (4)Ptot TC = 25℃: 125 W; (5)Md Mounting torque: 0.8 to 1.2 Nm; (6)Weight: 6 g; (7)IFRMS TVJ = TVJM: 70 A; (8)IFAVM TC = 85℃; rectangular, d = 0.5: 37 A; (9)IFRM tP < 10 μs; rep. rating, pulse width limited by TVJM: 375 A.

Features

DESI30-06A features: (1)International standard package JEDEC TO-247 AD; (2)Planar passivated chips; (3)Very short recovery time; (4)Extremely low switching losses; (5)Low IRM-values; (6)Soft recovery behaviour; (7)Epoxy meets UL 94V-0.

Diagrams

DESI30-06A Dimensions
