ISL81483IB

transceiver, Low Power, 12V, 120μA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	0.80 / Piece
51 ~ 500 :	0.60 / Piece
501 ~ 5000 :	0.40 / Piece

PartNumber:: ISL81483IB

Brand:: Intersil Corporation - Intersil | Pack: | D/C: 11+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Chan's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-12

From Other Seller

Part Number:ISL81483IB
US $0.40 - 0.80
Quantity:

piece

Product Summary

The ISL81483IB is a Low Power, High Speed or Slew Rate Limited Transceiver. Slew rate limited drivers on the ISL81483IB reduce EMI, and minimize reflections from improperly terminated transmission lines, or unterminated stubs in multidrop and multipoint applications. Data rates up to 250kbps are achievable with these devices. Applications include High Node Count Networks, Automated Utility Meter Reading Systems, Factory Automation, Security Networks, Building Environmental Control Systems and industrial/Process Control Networks.

Parametrics

ISL81483IB absolute maximum ratings: (1)VCC to Ground: 7V; (2)Input Voltages DI, DE, RE: -0.5V to (VCC +0.5V); (3)Input/Output Voltages A/Y, B/Z: -8V to +12.5V; (4)Input/Output Voltages RO: -0.5V to (VCC +0.5V); (5)Short Circuit Duration Y, Z: Continuous; (6)ESD Rating HBM (Per MIL-STD-883, Method 3015.7): >7kV.

Features

ISL81483IB features: (1)Fractional Unit Load Allows up to 256 Devices on the Bus; (2)Specified for 10% Tolerance Supplies; (3)Class 3 ESD Protection (HBM) on all Pins: >7kV; (4)Slew Rate Limited Versions for Error Free Data ; (5)Transmission up to 250kbps; (6)Low Quiescent Supply Current: 120μA (Max.); (7)-7V to +12V Common Mode Input Voltage Range; (8)Three State Rx and Tx Outputs; (9)30ms Propagation Delays, 5ns Skew (ISL81487); (10)Half Duplex Pinouts; (11)Operate from a Single +5V Supply (10% Tolerance); (12)Current Limiting and Thermal Shutdown for driver Overload Protection.
