MAX1483CSA+

low-power transceiver, 20μA, 250kbps, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	0.40 / Piece
51 ~ 500 :	0.30 / Piece
501 ~ 5000 :	0.20 / Piece

PartNumber:: MAX1483CSA+

Brand:: Maxim Integrated Products - Maxim | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Chan's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-04

From Other Seller

Part Number:MAX1483CSA+
US $0.20 - 0.40
Quantity:

piece

Product Summary

The MAX1483CSA+ is a low-power transceiver for RS-485 and RS-422 communication. Both feature slew-rate-limited drivers that minimize EMI and reduce reflections caused by improperly terminated cables. Data rates are guaranteed up to 250kbps. The MAX1483CSA+ draw only 20μA of supply current. Additionally, they have a low-current shutdown mode that consumes only 0.1μA. Both parts operate from a single +5V supply. Applications include Low-Power RS-485/RS-422 Networks, Transceivers for EMI-Sensitive Applications, Industrial-Control Local Area Networks and Large 256-Node LANs.

Parametrics

MAX1483CSA+ absolute maximum ratings: (1)Supply Voltage (VCC): 7V; (2)Control Input Voltages (RE, DE): -0.5V to (VCC + 0.5V); (3)Driver Input Voltage (DI): -0.5V to (VCC + 0.5V); (4)Driver Output Voltages: -7.5V to 12.5V; (5)Receiver Input Voltages (A, B): -7.5V to 12.5V; (6)Receiver Output Voltage (RO): -0.5V to (VCC + 0.5V; (7)Operating Temperature Ranges: 0℃ to +70℃; (8)Storage Temperature Range: -65℃ to +160℃; (9)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX1483CSA+ features: (1)Low 20μA Operating Current; (2)Slew-Rate Limited for Reduced EMI and Reduced Reflections; (3)0.1μA Low-Current Shutdown Mode; (4)Designed for RS-485 and RS-422 Applications; (5)Operate from a Single +5V Supply; (6)-7V to +12V Common-Mode Input Voltage Range; (7)Current Limiting and Thermal Shutdown for Driver Overload Protection.
