Product Summary

The PVN012AS-TPBF Photovoltaic Relay at 50 milliohms features the lowest possible on-state resistance in a miniature package lower than a comparable reed relay. The PVN012AS-TPBF is a single-pole, normally open solidstate relay. It utilizes a HEXFET MOSFET output switch, driven by an integrated circuit photovoltaic generator of novel construction. The output switch is controlled by radiation from a GaAlAs light emitting diode (LED) which is optically isolated from the photovoltaic generator. The PVN012AS-TPBF relay is packaged in a 6-lead molded DIP package with either thru-hole or surface mount (gull-wing) terminals. It is available in standard plastic shipping tubes or on tapeand-reel. Please refer to part identification information.

Parametrics

PVN012AS-TPBF absolute maximum ratings: (1)Minimum Dielectric Strength, Input-Output: 4000 VRMS; (2)Minimum Insulation Resistance, Input-Output: 10(12) Ω; (3)Maximum Capacitance, Input-Output, Vd =0V, f = 1MHz: 1.0 pF; (4)Maximum Pin Soldering Temperature: +260; (5)Ambient Temperature Range: Operating: -40 to +85 ℃.

Features

PVN012AS-TPBF features: (1)50mΩ On-Resistance; (2)Bounce-free Operation; (3)4.0 - 6.0 Amp Capacity; (4)Linear AC/DC Operation; (5)4,000 VRMS I/O Isolation; (6)Solid-State Reliability; (7)UL Recognition Pending; (8)ESD Tolerance.

Diagrams

PVN012AS-TPBF Connection Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PVN012AS-TPBF
PVN012AS-TPBF
International Rectifier
Solid State Relays 20V 1 Form A Photo Voltaic Relay
Data Sheet
0-1: $5.56
1-25: $4.06
25-100: $3.22
100-250: $3.10
