Product Summary
The BYT261PIV-400 rectifier is suited for free-wheeling function in converters and motor control circuits. Packaged in ISOTOP or SOD93, BYT261PIV-400 is intended for use in Switch Mode Power Supplies.
Parametrics
BYT261PIV-400 absolute maximum ratings: (1)VRRM Repetitive peak reverse voltage: 400 V; (2)IFRM Repetitive peak forward current: 1000 A; (3)IF(RMS) RMS forward current: 140 A; (4)IF(AV) Average forward current: 60 A; (5)IFSM Surge non repetitive forward current: 600 A; (6)Tstg Storage temperature range: - 40 to + 150 ℃; (7)Tj Maximum operating junction temperature: 150 ℃.
Features
BYT261PIV-400 features: (1)very low reverse recovery time; (2)very low switching losses; (3)low noise turn-off switching; (4)insulated package: isotop.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BYT261PIV-400 |
STMicroelectronics |
Rectifiers 2X60 Amp 400 Volt |
Data Sheet |
Negotiable |
|
||||||||||||
