Product Summary
The LMC7215IM5X is a ultra low power comparator with a maximum of 1μA power supply current. It is designed to operate over a wide range of supply voltages, from 2V to 8V.
Parametrics
LMC7215IM5X absolute maximum ratings: (1)ESD Tolerance: 2 kV; (2)Differential Input Voltage: (VCC)+0.3V to (-VCC)-0.3V; (3)Voltage at Input/Output Pin: (VCC)+0.3V to (-VCC)-0.3V; (4)Supply Voltage (V+– V-): 10V; (5)Current at Input Pin: ±5 mA; (6)Current at Output Pin: ±30 mA; (7)Current at Power Supply Pin: 40 mA; (8)Storage Temperature Range: -65℃ to +150℃ ; (9)Junction Temperature: 150℃.
Features
LMC7215IM5X features: (1)Typical unless otherwise noted); (2)Ultra low power consumptio0.7 μA; (3)Wide range of supply voltages 2V to 8V; (4)Input common-mode range beyond V+ and V-; (5)Opecollector and push-pull output; (6)High output current drive: (@ VS; (7)= 5V) 45 mA; (8)Propagatiodelay (@ VS; (9)= 5V, 10 mV overdrive) 25 μs; (10)Tiny SOT23-5 package; (11)Latch-up resistance >300 mA.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LMC7215IM5X |
National Semiconductor (TI) |
Comparator ICs |
Data Sheet |
|
|
||||||||||
 |
LMC7215IM5X/NOPB |
National Semiconductor (TI) |
Comparator ICs |
Data Sheet |
|
|
||||||||||
