ST232ABD

transcevier, 4.5V, 1.5mA, 400kbp/s, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.35~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	0.70 / Piece
51 ~ 500 :	0.50 / Piece
501 ~ 5000 :	0.35 / Piece

PartNumber:: ST232ABD

Brand:: STMicroelectronics - ST | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Chan's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-13

From Other Seller

Part Number:ST232ABD
US $0.35 - 0.70
Quantity:

piece

Product Summary

The ST232ABD is a 2 driver, 2 receiver device following EIA/TIA-232 and V.28 communication standard. It is particularly suitable for applications where ±12V is not available. The ST232ABD uses a single 5V power supply and only four external capacitors (0.1µF). Typical applications are in: Portable Computers, Low Power Modems, Interfaces Translation, Battery Powered RS-232 System and Multi-Drop RS-232 Networks.

Parametrics

ST232ABD absolute maximum ratings: (1)Supply Voltage -0.3 to 6 V; (2)Extra Positive Voltage: (VCC -0.3) to 13.2 V; (3)Extra Negative Voltage: 0.3 to -13.2 V; (4)Transmitter Input Voltage Range: -0.3 to (VCC + 0.3) V; (5)Receiver Input Voltage Range: ±30 V; (6)Transmitter Output Voltage Range: ±15 V; (7)Receiver Output Voltage Range: -0.3 to (VCC + 0.3) V.

Features

ST232ABD features: (1)Supply Voltage range from 4.5V to 5.5V; (2)supply current no load: 1.5mA; (3)transition slew rate: 12V/μs; (4)receiver input voltage range: ±30V; (5)data rate: 400kbp/s.
