ST3232CD

driver, 3V, 300μA, 300Kbps, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 50 :	0.60 / Piece
51 ~ 500 :	0.45 / Piece
501 ~ 5000 :	0.30 / Piece

PartNumber:: ST3232CD

Brand:: STMicroelectronics - ST | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 50000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Mr. Chan's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-13

From Other Seller

Part Number:ST3232CD
US $0.30 - 0.60
Quantity:

piece

Product Summary

The ST3232CD is a 3V powered EIA/TIA-232 and V.28/V.24 communication interface with low power requirements, high data-rate capabilities. ST3232CD has a proprietary low dropout transmitter output stage providing true RS-232 performance from 3 to 5.5V supplies. The device requires only four small 0.1mF standard external capacitors for operations from 3V supply. The ST3232CD has two receivers and two drivers. The device is guaranteed to run at data rates of 250Kbps while maintaining RS-232 output levels. Typical applications are Notebook, Subnotebook and Palmtop Computers, Battery Powered Equipment, Hand-Held Equipment, Peripherals and Printers.

Parametrics

ST3232CD absolute maximum ratings: (1)Supply voltage: -0.3 to 6 V; (2)Doubled voltage terminal: (VCC - 0.3) to 7 V; (3)Inverted voltage terminal: 0.3 to -7 V; (4)Transmitter input voltage range: -0.3 to 6 V; (5)Receiver input voltage range: ± 25 V; (6)Transmitter output voltage range； ± 13.2 V; (7)Receiver output voltage range: -0.3 to (VCC + 0.3) V.

Features

ST3232CD features: (1)300μA supply current; (2)300Kbps minimum guaranteed data rate; (3)6V/μs minimum guaranteed slew rate; (4)Meet EIA/TIA-232 specifications down to 3V; (5)Available in DIP-16, SO-16, SO-16 large and TSSOP16.
